- Heating power 2,2 to 10,5 kW
- Heating up to -7ºC outside
- Cooling up to +48ºC outside
- Refrigerant R410A
- Wi-Fi readiness
- 100% Copper Condenser
- Anti-Dust Air Filtration
- Auto Smart Check
- ECO-friendly Refrigerant
- Turbo Mode
- Wireless LED Remote Control
SPECIFICATIONS
| EI07AA-AIRPRO | EI09AA-AIRPRO | EI12AA-AIRPRO | EI18AA-AIRPRO | EI24AA-AIRPRO | EI36AA-AIRPRO | |||
| Rated Capacity | Cooling | W | 2200 | 2750 | 3600 | 5305 | 7100 | 10500 |
| Heating | W | 2250 | 2800 | 3650 | 5530 | 7380 | 10200 | |
| Rated Power Consumption | Cooling | W | 685 | 856 | 1121 | 1655 | 2210 | 3488 |
| Heating | W | 623 | 776 | 1011 | 1530 | 2044 | 3177 | |
| Rated Running Current | Cooling | A | 3,20 | 3,90 | 5,00 | 7,50 | 10,10 | 12,70 |
| Heating | A | 3,00 | 3,70 | 4,80 | 7,20 | 9,70 | 13,50 | |
| Max. Input Power | W | 925 | 1156 | 1513 | 2234 | 2984 | 4200 | |
| Max. Input Current | A | 4,20 | 5,25 | 6,88 | 10,16 | 13,56 | 19,09 | |
| EER Cooling Btu/h.W or W/W | W/W | 3,21 | 3,21 | 3,21 | 3,21 | 3,21 | 3,01 | |
| COP Heating | W/W | 3,61 | 3,61 | 3,61 | 3,61 | 3,61 | 3,21 | |
| Power supply source | V/Ph/Hz | 220-240V-1-50Hz | 220-240V-1-50Hz | 220-240V-1-50Hz | 220-240V-1-50Hz | 220-240V-1-50Hz | 220-240V-1-50Hz | |
| Refrigerant | R410A | R410A | R410A | R410A | R410A | R410A | ||
| Refrigerant Charged | g | 480 | 500 | 570 | 700 | 830 | 1600 | |
| Air Flow Volume | m³/h | 300/330/380/ 450/500 | 300/330/380/ 450/500 | 350/410/500/ 560/580 | 400/430/520/ 600/850 | 600/730/850/ 950/990 | 800/920/1100/ 1200/1250 | |
| IDU-Noise level | dB(A) | 20/24/27/31/33 | 20/24/27/31/33 | 22/26/31/33/36 | 24/28/33/37/39 | 26/32/35/39/41 | 28/32/38/42/50 | |
| ODU-Noise level | dB(A) | 50 | 50 | 51 | 53 | 54 | 60 | |
| Indoor unit weight (Net ) | Kg | 7 | 7 | 9 | 11 | 12 | 14 | |
| Outdoor unit weight (Net ) | Kg | 21 | 22 | 25 | 32 | 42 | 58 | |
| Indoor unit weight (Gross) | Kg | 9 | 9 | 11 | 13 | 14 | 17 | |
| Outdoor unit weight (Gross ) | Kg | 23 | 24 | 27 | 35 | 45 | 61 | |
| Indoor Net Dimension | mm | 700×250×190 | 700×250×190 | 810×290×190 | 910×320×230 | 970×340×230 | 1100×320×230 | |
| Indoor Packing Dimension | mm | 775×320×275 | 775×320×275 | 875×375×275 | 985×375×305 | 1035×395×305 | 1165×395×305 | |
| Power Supply cable lenght | m | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
| Condensate Drainage Pipe (O.D) | Φ16 | Φ16 | Φ16 | Φ16 | Φ16 | Φ16 | ||
| Condensate Drainage Pipe (L) | mm | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | |
| Liquid Valve | inch | 1/4 | 1/4 | 1/4 | 1/4 | 1/4 | 1/4 | |
| Gas Valve | inch | 3/8 | 3/8 | 3/8 | 1/2 | 1/2 | 5/8 | |
| Compressor Type | ROTARY | ROTARY | ROTARY | ROTARY | ROTARY | ROTARY | ||
| Compressor Brand | GREE | GREE | GREE | GMCC | GREE | GREE | ||
| Throttling gear | Capillary | Capillary | Capillary | Capillary | Capillary | Capillary | ||
| Outdoor Net Dimension (WidthxDepthxHeight | mm | 700x266x422 | 700x266x422 | 700x266x422 | 838x295x600 | 853x322x655 | 920x337x700 | |
| Outdoor Packing Dimension (WidthxDepthxHeight) | mm | 775x315x495 | 775x315x495 | 775x315x495 | 915x390x640 | 933x422x700 | 1020x430x755 | |
| Max pipe length | m | 20 | 20 | 20 | 25 | 25 | 25 | |
| Max height difference | m | 8 | 8 | 9 | 12 | 12 | 15 | |
| Standard pipe length (no additional refrigerant required) | m | 3,5 | 3,5 | 3,5 | 3,5 | 3,5 | 3,5 | |
| Ambient temperature (cooling) | ºC | +16 ~ +48 | +16 ~ +48 | +16 ~ +48 | +16 ~ +48 | +16 ~ +48 | +16 ~ +48 | |
| Ambient temperature (heating) | ºC | -7 ~ +24 | -7 ~ +24 | -7 ~ +24 | -7 ~ +24 | -7 ~ +24 | -7 ~ +24 |
